特點
全不鏽鋼結構（304）
產品區域易於清潔
驅動系統內嵌技術，機器可用水清洗
防護等級: IP65
多功能套裝軟體
技術規格
X光類型: 整合式X光產生器，配備風冷系統
X光成像儀: 二極體成像板，解析度400 μm
掃描寬度: 300 mm
掃描速度: 90 公尺/分鐘
顯示器: 15吋彩色TFT觸控螢幕
掃描區的輸送帶長度: 800 / 1500 / 1800 mm
SC-E
The SC-E is the perfect entry to the world of ultra-modern X-ray inspection
systems and the associated high quality product line of WIPOTEC-OCS.
Designed and developed to meet the most stringent requirements of foreign
body detection, with an optional comprehensive software package, the scanner
becomes an excellent all-rounders that reliably performs count, completeness,
fill-level checks, and mass determination. It represents a well-engineered,
technical and economical solution at a highly competitive price.
Highlights
Complete stainless steel model (304)
Easy to clean product area
Built-in drive technology that is able to wash the machine with water directly
Protection class is IP65
Comprehensive software package
Technical Data
X-ray type: monoblock with air-cooled
X-ray sensor: diode array technology with 400 μm resolution
Scanning width: 300 mm
Scanning speeds: 90 m/min
Display: 15-inch colour TFT with touchscreen
Scanner belt lengths: 800 / 1500 / 1800
特點
全不鏽鋼結構（304）
產品區域易於清潔
驅動系統內嵌技術，機器可用水清洗
防護等級: IP65
檢查標籤和條碼的可讀性與位置
X光機、重量檢測機、光學檢測整合於一台設備
技術規格
X光類型: 整合式X光產生器，配備風冷或水冷式金屬陶瓷管
X光成像儀: TDI相機，解析度160 μm
掃描寬度: 300 mm
掃描速度: 120 公尺/分鐘
顯示器: 19吋彩色TFT觸控螢幕
秤重範圍: 750 - 7500 g
校正精度: 0.1 g
標準偏差: 大於50 mg
光學影像畫素: 73 μm以下
The SC-W-V is a pioneering combination of innovative X-ray technology, proven
checkweigher technology and optical inspection from WIPOTEC-OCS. The
products in the accepted goods stream are checked not only for impurities and
weight,but also undergo an optical inspection. This control system checks the
information as it appears on the products (barcodes, ingredients, nutritional
values, expiry date and more) for correctness and a flawless appearance
regarding the proper positioning and readability of all labels and seals (OCR and
OCV). All inspection units - X-ray, weighing and optical inspection - are
combined in one space-saving design.
Highlights
Complete stainless steel model (304)
Easy to clean product area
Built-in drive technology that is able to wash the machine with water directly
Protection class is IP65
Legibility check and position control of all labels and codes
X-ray scanner, checkweigher, and vision system in one unit
Technical Data
X-ray type: Metal-ceramic tube with integrated water cooling system or
air-cooled monoblock
X-ray sensor: Long-life camera technology with 160 μm resolution
Scanning width: 300 mm
Scanning speeds: 120 m/min
Display: 19-inch colour TFT with touchscreen
Gross weight range: 750 – 7500 g
Calibration value: 0.1 g
Standard deviation: >50 mg
Optical sensor resolution: 73 μm pixel size
